Solar System Inverter 3.6kw 6.2kw Grid Solar Converter 48V 220V Pure Sine Wave Inverter AC Home Use

  • Pure sine wave inverter
  • Configurable input voltage range for home appliances and personal computers via LCD setting
  • Configurable battery charging current based on applications via LCD setting
  • Configurable AC/Solar Charger priority via LCD setting
  • Compatible to mains voltage or generator power
  • Auto restart while AC is recovering
  • Overload/Over temperature/short circuit protection
  • Smart battery charger design for optimized battery performance
  • Cold start function

Inquire

ON/OFF GRID SOLAR INVERTER

This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

● Pure sine wave inverter.

● Configurable input voltage range for home appliances and personal computers via LCD setting

● Configurable battery charging current based on applicationsvia LCD setting

● Configurable AC/Solar Charger priority via LCD setting

● Compatible to mains voltage or generator power

● Auto restart while AC is recovering

● Overload/Over temperature/ short circuit protection

● Smart battery charger design for optimized battery performance

● Cold start function

3.6KW Solar Inverter (On/Off Grid) (120VAC)
(Can Work Without Battery)

Model: STE36224
Rated Output Power: 3600W
Nominal Operating Voltage: 360VDC
Maximum PV Array Open Circuit Voltage: 500VDC
MPPT Operating Voltage: 60~450VDC
Full Load MPPT Operating Voltage: 240~450VDC
Number Of MPPT/Maximum Input Current: 1/23A
Maximum PV Charging Current: 120A
Feed-In Grid Voltage: 120VAC, 50/60Hz
Nominal Output Voltage: 120VAC, 50/60Hz
Maximum Main Load: 3600W
Maximum Second Load: 1200W
Main Load Cut Off/Return Voltage: 22V/26VDC
Nominal Input Voltage: 120VAC, 50/60Hz
Maximum AC Charging Current: 80A
Battery Voltage: 24VDC
Communication: RS232/GPRS/WIFI/LITHIUM BATTERY
Product Size: 310x420x110mm
Net Weight: 8.8kg
Warranty: 3 Years

6.2KW Solar Inverter (On/Off Grid)
(Can Work Without Battery)

Model ：STE62248
Rated Output Power: 6200W
Nominal Operating Voltage: 360VDC
Maximum PV Array Open Circuit Voltage: 500VDC
MPPT Operating Voltage: 60~450VDC
Full Load MPPT Operating Voltage: 240~450VDC
Number Of MPPT/Maximum Input Current: 1/23A
Maximum PV Charging Current: 120A
Feed-In Grid Voltage: 230VAC, 50/60Hz
Nominal Output Voltage: 230VAC, 50/60Hz
Maximum Main Load: 6200W
Maximum Second Load: 2066W
Main Load Cut Off/Return Voltage: 44V/52VDC
Nominal Input Voltage: 230VAC, 50/60Hz
Maximum AC Charging Current: 100A
Battery Voltage: 48VDC
Communication: RS232/GPRS/WIFI/LITHIUM BATTERY
Product Size: 334x423x110mm
Net Weight: 10kg
Warranty: 3 Years

A: Yes, all our inverters provide true pure sine wave output.

A: Yes, all our inverters provide true pure sine wave output.

A: Low frequency inverters have various protections, strong adaptability to the environment, and are more reliable with voltage regulation.

A: Pure sine wave output inverters provide power quality equivalent to or better than the public power grid. They have a low repair rate, long lifespan, no harmonic pollution, and are environmentally friendly. Modified sine wave output inverters have a negative impact on appliances and cannot load inductive loads, such as air conditioners and refrigerators. Certain motor control circuits may not be compatible with modified sine wave inverters.

A: Our inverters can be used with household, office, agricultural appliances, and other inductive loads such as refrigerators, air conditioners, water pumps, etc.

A: Yes, we accept OEM orders and can customize the products with your company logo.

A: Simply tell us your requirements, and our sales team will recommend a suitable inverter for you.

A: We offer 24-hour after-service consultancy to help you easily solve any technical problems you may encounter.

A: While a power inverter is not absolutely required for a solar energy system, it is necessary if you want to use normal AC appliances. Without a power inverter, you will only have battery power and won’t have 220 or 230 volts AC. This may be acceptable for small RVs or cabins.

A: If any product is faulty, please send us a picture or video, and we will study it. We provide free spare parts of the PCB board for after-sale service.
