Solar Inverter 8.2kw 10.2kw On&Off Grid 220v Inverters For Solar PanelInverter For Home Solar System

  • Pure sine wave solarinverter (on/off Grid) Inverter running without battery
  • Output power factor 1.0
  • High PVinput voltage range(90-500VDC)
  • WIFI&GPRS available for IOS and Android
  • Built-in anti-dusk kit for harsh environment
  • Built-in 160A(for 8.2KW)/180A (for 10.2KW) MPPT solar charge
  • Smart battery charge design to optimize battery life
  • One-click restoration to factory Settings
  • Dual output
  • Built-in Lithium battery automatic activation
  • Touch buttom

Inquire

Hybrid solar inverter with MPPT charge controller is a new type of all-in-one hybrid solar inverter charger, multi-function inverter/charger, which combines the functions of inverter, solar charger and battery charger to provide uninterruptible power supply support in portable size. Support dual PV input, dual MPPT voltage tracking. RGB flexible with different working modes (purple photovoltaic mode; Red battery mode, blue utility mode).

● Pure sine wave solarinverter (on/off Grid) Inverterrunning without battery

● WIFI&GPRS available for IOS and Android

● Built-in anti-dusk kit for harsh environment

● Smart battery charge design to optimize battery life

● One-click restoration to factory Settings

● Built-in Lithium battery automatic activation

8.2KW Solar Inverter (On/Off Grid)

Model: STM82248
Rated Output Power: 8200W
Nominal Operating Voltage: 360VDC
Maximum PV Array Open Circuit Voltage: 500VDC
MPPT Operating Voltage: 90~450VDC
Full Load MPPT Operating Voltage: 360~450VDC
Number Of MPPT/Maximum Input Current: 1/27A
Maximum PV Charging Current: 160A
Feed-In Grid Voltage: 230VAC, 50/60Hz
Nominal Output Voltage: 230VAC, 50/60Hz
Maximum Main Load: 8200W
Maximum Second Load: 2733W
Main Load Cut Off /Return Voltage: 44V/52VDC
Nominal Input Voltage: 230VAC, 50/60Hz
Maximum AC Charging Current: 140A
Battery Voltage: 48VDC
Communication Port: RS232/GPRS/WIFI/LITHIUM BATTERY
Product Size: 390x530x130mm
Net Weight: 14.2kg
Warranty: 3 Years

10.2KW Solar Inverter (On/Off Grid)

Model ：STM102248
Rated Output Power: 10200W
Nominal Operating Voltage: 360VDC
Maximum PV Array Open Circuit Voltage: 500VDC
MPPT Operating Voltage: 90~450VDC
Full Load MPPT Operating Voltage: 360~450VDC
Number Of MPPT/Maximum Input Current: 1/27A
Maximum PV Charging Current: 160A
Feed-In Grid Voltage: 230VAC, 50/60Hz
Nominal Output Voltage: 230VAC, 50/60Hz
Maximum Main Load: 10200W
Maximum Second Load: 3400W
Main Load Cut Off /Return Voltage: 44V/52VDC
Nominal Input Voltage: 230VAC, 50/60Hz
Maximum AC Charging Current: 140A
Battery Voltage: 48VDC
Communication Port: RS232/GPRS/WIFI/LITHIUM BATTERY
Product Size: 390x530x130mm
Net Weight: 14.5kg
Warranty: 3 Years

A: Yes, all our inverters provide true pure sine wave output.

A: Yes, all our inverters provide true pure sine wave output.

A: Low frequency inverters have various protections, strong adaptability to the environment, and are more reliable with voltage regulation.

A: Pure sine wave output inverters provide power quality equivalent to or better than the public power grid. They have a low repair rate, long lifespan, no harmonic pollution, and are environmentally friendly. Modified sine wave output inverters have a negative impact on appliances and cannot load inductive loads, such as air conditioners and refrigerators. Certain motor control circuits may not be compatible with modified sine wave inverters.

A: Our inverters can be used with household, office, agricultural appliances, and other inductive loads such as refrigerators, air conditioners, water pumps, etc.

A: Yes, we accept OEM orders and can customize the products with your company logo.

A: Simply tell us your requirements, and our sales team will recommend a suitable inverter for you.

A: We offer 24-hour after-service consultancy to help you easily solve any technical problems you may encounter.

A: While a power inverter is not absolutely required for a solar energy system, it is necessary if you want to use normal AC appliances. Without a power inverter, you will only have battery power and won’t have 220 or 230 volts AC. This may be acceptable for small RVs or cabins.

A: If any product is faulty, please send us a picture or video, and we will study it. We provide free spare parts of the PCB board for after-sale service.
